Super Wispaset 100 super silenced pump

The Super Wispaset 100 is a medium sized super silenced pump with a maximum head of 31 metres and a maximum flow rate of 45 litres per second. One of the quietest pumps of its size on the market, this particular model features float level control and can be configured to modern telemetry technology to allow remote monitoring, negating the need for engineers to visit site. The Super Wispaset 100 is a self-contained bunded unit, preventing potential oil spillages on site. It is suitable for a range of applications including over-pumping and wastewater transfer.

Key Features

Feature

Low noise operation

Fuel efficient operation

Integral fuel tank

Easily changeable shaft seals

Compact and manoeuvrable

Solids handling

up to 44 mm

Automatic priming and re-priming

Hard wearing cast iron parts

Product Specification

Performance : Max head: 31 m
Max flow: 45 l/s
Max solid: 44 mm
Weight : 1685 kg with fuel
1500 kg without fuel
Dimensions (L x W x H) : 2137 x 1250 x 1535 mm
Noise level : @ 7m = 58 – 65 dBA
Fuel capacity : 158 litres. Max 24 hours
Pipe connections : Suction
Fuel Consumption : Full load @ 1800 rpm: 5 litres/hour
Energy Efficient duty point : Fuel Consumption @ 1500 rpm: 2.25 litres/hour

Downloads

Accessories

4″ SPLIT INTAKE
4″ X 3M W/A BAUER HOSE
4″ 20FT W/A SUCTION HOSE BAUER
4″ 20FT POLYTUBE
4″ X 6M HELIFLEX PVC BAUER
4″ LAYFLAT HOSE PER METRE
4″ BLUE LAYFLAT X 25M CW BAUERS
4″ X 6MTR STEEL BAUER PIPE
4″ 45* BAUER BEND
4″ 90* BEND
4″ GATEVALVE
4″ NON RETURN VALVE
SETTLEMENT TANK
SYKES SILT AWAY
ROAD RAMP C/W 6″ PN16 FLANGES
ROAD RAMP WIDE C/W 6″ PN16 FLANGES
ROAD CROSSING C/W 8″ PN16 FLANGES
BUNDED FUEL TANK 2000 LITRE
BUNDED FUEL TANK 2800 LITRE
BUNDED FUEL TANK 3000 LITRE
5M HP FUEL LINE
RETAIL GAS OIL

Sectors

Clean and dirty water
Emergency sewer repairs
Sludge
Utilities
Light slurry
Quarries
Over pumping
Civil engineering
Site dewatering
Wastewater
